Products
-
-
OPTICAL
19x50W RGBW
-
LUMEN OUTPUT
9,450 lm
-
ANGLE
5°-46°
-
MEASUREMENT
387*290*488mm
-
WEIGHT
22KG
Product
Parameters
Optical
Light Source: 19 pcs 50W RGBW 4 in 1 LED, 144*0.2W RGB LED
Color Temperature: 2800K-10000K adjustable
Beam Angle: 5°-46°
Luminaire Output: 9,450lm
Illuminance (5°): 36,500lux @ 5m
Illuminance (46°): 1,350lux @ 5m
PWM Options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz
Dynamic effect
LED：pixel control
Selectable Pan Ranges: 180°, 360°, 540°
Selectable Tilt Ranges: 90°, 180°, 260°
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-25Hz, selectable multiple strobe effects with different speeds.
Zoom: Motorized
Color Mixing：RGBW mixing or CMY mixing
Outer Ring: 12 sections control
Appearance
Size: 387*290*488mm
Weight: 22KG
Housing Colors: Black
Housing Material: Aluminum alloy
IP Rated: IP65/IP66
Connection
Control Protocol: DMX, RDM, ArtNet, Kling-Net, sACN
DMX (Single Mode): 33, 39, 145, 265, 327
DMX (Dual Mode-Movement): 13, 36, 47
DMX (Dual Mode-Pixel): 93, 112, 224
IP65 rated 3 pin XLR input/output, Ethernet input/output
USB software upload enable
Electrical / Temperature
Input Voltage: AC 100V-240V, 50/60Hz
Power: 1150W
Working temperature: -40°-45°
Startup temperature: -20°-45°
 |
LED SOURCE | |||
RED | GREEN | BLUE | WHITE |
PIXEL CONTROL 19x50W LED |
 |
PHOTOMETRICS |
 |
