OPTICAL
27x40W RGBW
-
LUMEN OUTPUT
15,500 lm
-
ANGLE
4.8°-54°
-
MEASUREMENT
476*369*536mm
-
WEIGHT
31KG
Product
Parameters
Optical
Light Source: 27 pcs 40W RGBW 4 in 1 LED
Color Temperature: 2800K-10000K adjustable
Beam Angle: 4.8°-54°
Luminaire Output: 15,582lm
Illuminance (4.8°): 40,870lux @ 5m
Illuminance (54°): 1,702lux @ 5m
PWM Options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz
Dynamic effect
LED：pixel control
Selectable Pan Ranges: 180°, 360°, 540°
Selectable Tilt Ranges: 90°, 180°, 270°
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-20Hz, selectable multiple strobe effects with different speeds.
Zoom: Motorized
Color Mixing：RGBW mixing or CMY mixing
Pan/Tilt/Color Blackout Optional
Appearance
Size: 476*369*536mm
Weight: 31KG
Housing Colors: Black
Housing Material: High-impact flame-retardant polymer
Connection
Control Protocol: DMX, RDM, ArtNet, Kling-Net, sACN, WDMX(*optional)
DMX (Single Mode): 21, 129, 243, 297
DMX (Dual Mode) Movement: 9, 21, 27
DMX (Dual Mode) Pixel: 81, 108, 216
Control Mode: DMX, Manual, Auto
3 pin/5pin XLR input/output ethernet input/output
Electrical / Temperature
Input Voltage: 100V-240V, 50/60Hz
Power and Current: 1,100W, 4.8A @ 230V, 50Hz
Temperature (Ambient): -5° to 45°
 Excellent lighting will give the stage unlimited imagination |
Light source LED SOURCE | |||
RED | GREEN | BLUE | WHITE |
 |  |  |  |
Single-point single-control PIXEL CONTROL 27x40W LED |
 |
Illuminance diagram PHOTOMETRICS |
