OPTICAL

6x15W RGBW
LUMEN OUTPUT

1,225 lm
ANGLE

5°
MEASUREMENT

498*95*179mm
WEIGHT

5KG

Product

Parameters

Optical

Light Source: 6 pcs 15W RGBW 4 in 1 LED
Beam Angle: 5°
Luminaire Output: 1,225lm
Illuminance (5°): 12,500lux @ 5m

Dynamic effect

Selectable Tilt Ranges: 90°, 180°, 270°
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-20Hz, selectable multiple strobe effects with different speeds.
Pan/Tilt/Color Blackout Optional

Appearance

Size: 498*95*179mm
Weight: 5KG
Housing Colors: Black
Housing Material: High-impact flame-retardant polymer

Connection

Control Protocol: DMX, RDM
DMX Channels: 18, 47, 53, 80
Control Mode: DMX, Manual, Auto
3 pin XLR input

Electrical / Temperature

Input Voltage: 200V-240V, 50/60Hz
Power and Current: 115W, 0.5A @ 230V, 50Hz
Temperature (Ambient): -5℃-40℃

Technology

Support

Technical documents are updated irregularly

USER MANUAL

T1X BAR#MANUAL-CN (size:790.2KB)

LIBRARY

T1X BAR#GDTF_Build_No_1 (size:1.7MB)

USER MANUAL

T1X BAR#MANUAL-EN (size:663.3KB)

CHANNEL CHART

T1X BAR#DMX-EN (size:398.8KB)

LIBRARY

T1X BAR#MA2 LIBRARY (size:24.2KB)

CHANNEL CHART

T1X BAR#DMX-CN (size:408.5KB)

DRAWING

T1X BAR#CAD (size:265.5KB)

LIBRARY

T1X BAR#TIGER (size:2.8KB)
