CL-800 BSWF
CL-800 BSWF
CL-800 BSWF
CL-800 BSWF

  • OPTICAL

    600W LED

  • LUMEN OUTPUT

    28,500 lm

  • ANGLE

    5.5°-58.6°

  • MEASUREMENT

    382*263*696mm

  • WEIGHT

    27.5KG

Product

icon

Parameters

Optical

Light Source: 600W white LED module
Color Temperature: 7,000 K
Beam Angle: 5.5°-58.6°
Luminaire Output: 28,500lm
Illuminance (5.5°): 71,844lux @ 5m
Illuminance (58.6°): 2,938lux @ 5m
PWM Options: 600Hz, 1200Hz, 4000Hz, 6000Hz, 15000Hz

Dynamic effect

Selectable Pan Ranges: 180°, 360°, 540°
Selectable Tilt Ranges: 90°, 180°, 270°
Colors: CMY, CTO
Colors: 5+CRI90+8000K CTB+white, split colors, rainbow effects at variable speeds.
Gobos 1: 7 rotating glass gobos+open, interchangeable gobos, indexing, rainbow effects at variable speeds
Gobos 2: 9 static glass gobos+open, rainbow effects at variable speeds.
Framing Shutters: 4 individual shutter blades, rotation of module is 120°
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-25Hz, selectable multiple strobe effects with different speeds.
Focus: Motorized
Zoom: Motorized
Iris: Motorized
Prism: 5-facet prism, rotating at variable speeds.
Frost: Light frost

Appearance

Size: 382*263*696mm
Weight: 27.5KG
Housing Colors: Black
Housing Material: Magnesium alloy
IP rated: IP65/IP66

Connection

Control Protocol: DMX, RDM.
Only for Connector version: ArtNet, sACN
DMX Channels: 32, 48
Connector version: 3-pin XLR, EtherCON, Powerkon
Attached cable version: 1.4m input and output cable tail with 3-pin XLR connectors, 1.4m input cable tail with Power connector.

Electrical / Temperature

Input Voltage: 200V-240V, 50/60Hz
Power and Current: 1050W, 4.56A @ 230V, 50Hz
Working temperature: -40°-45°
Startup temperature: -20°-45°





CMY COLOR

CMY



CTO

CYAN

MAGENTA

YELLOW



2700K


0%

100%

0%

100%

0%

100%

 0%

100%









COLOR WHEEL

COLOR 1

COLOR 2

COLOR 3

COLOR 4

COLOR 5

COLOR 6

COLOR 7









ROTATING GOBO

R GOBO 1

R GOBO 2

R GOBO 3

R GOBO 4

R GOBO 5

R GOBO 6

R GOBO 7









STATIC GOBO

S GOBO 1

S GOBO 2

S GOBO 3

S GOBO 4

S GOBO 5

S GOBO 6

S GOBO 7

S GOBO 8

S GOBO 9









PRISM



FROST



5-CIRCULAR PRISM



LIGHT









FRAMING SYSTEM



±60° ROTATION









PHOTOMETRICS
