Home

OPTICAL

54x RGBL/RGBW
LUMEN OUTPUT

34,200 lm
ANGLE

6°, 15°, 25°, 35°
MEASUREMENT

552*200*495mm
WEIGHT

23KG

Product

Parameters

Optical

Light Source: 54 pcs RGBL/RGBW 4 in 1 LED

LER (Limunous Efficiency Ratio): 57.0 lm/W

Color Temperature: 1800-10000K

Optics Angle: 6°/15°/25°/35°

Luminaire Output: 34,200lm

PWM Options: 600Hz, 1200Hz, 4000Hz, 6000Hz, 15000Hz

Dynamic effect

Dimmer: 0-100% electronics, 4 dimming curves options.

Strobe: 0-25Hz, selectable multiple strobe effects with different speeds.

LED：6 sections

Appearance

Size: 552*200*495mm

Weight: 23KG

Housing Colors: sky Grey

Housing Material: Magnesium alloy

IP rated: IP66

Connection

Control Protocol: DMX, RDM.

Input cable tail with 3-pin XLR connectors, power input cable tail

Electrical / Temperature

Input Voltage: 200V-240V, 50/60Hz

Power: 600W

Working temperature: -40°-45°

Startup temperature: -20°-45°

Technology

Support

Technical documents are updated irregularly

USER MANUAL

CL-6024 PANEL#MANUAL-CN (size:6.0MB)

LIBRARY

CL-6024 PANEL#GDTF_Build_No_1 (size:1.0MB)

USER MANUAL

CL-6024 PANEL#MANUAL-EN (size:5.6MB)

CHANNEL CHART

CL-6024 PANEL#DMX-EN (size:186.5KB)

LIBRARY

CL-6024 PANEL#MA2 LIBRARY (size:13.4KB)

CHANNEL CHART

CL-6024 PANEL#DMX-CN (size:381.0KB)

DRAWING

CL-6024 PANEL#CAD (size:404.8KB)

LIBRARY

CL-6024 PANEL#TIGER (size:2.9KB)
