OPTICAL

20x20W RGBW
LUMEN OUTPUT

12,240 lm
ANGLE

25° or 45°
MEASUREMENT

336*202*273mm
WEIGHT

6.6KG

Product

Parameters

Optical

Light Source: 20 pcs 20W RGBW 4 in 1 LED
Beam Angle: 25°or 45°
Luminaire Output: 12,240lm
Illuminance (25°): 9,470lux @ 5m
Illuminance (45°): 2,080lux @ 5m
PWM Options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz

Dynamic effect

LED: 2 sections control
Tilt angle: manual adjust
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-25Hz, selectable multiple strobe effects with different speeds.
Color System: RGBW or CMY color mixing

Appearance

Size: 336*202*273mm
Weight: 6.6KG
Housing Colors: Black
Housing Material: Aluminum alloy
IP Rated: IP66

Connection

Control Protocol: DMX, RDM
DMX channels: 15, 28, 30, 45
IP65 rated 3 pin XLR input/output

Electrical / Temperature

Input Voltage: AC 100V-240V, 50/60Hz
Power: 410W
Working temperature: -40℃-45℃
Startup temperature: -20℃-45℃

Technology

Support

Technical documents are updated irregularly

USER MANUAL

TOUGH 400 PANEL#MANUAL-CN (size:1.6MB)

LIBRARY

TOUGH 400 PANEL#GDTF_Build_No_1 (size:1.1MB)

USER MANUAL

TOUGH 400 PANEL#MANUAL-EN (size:8.6MB)

CHANNEL CHART

TOUGH 400 PANEL#DMX-EN (size:320.8KB)

LIBRARY

TOUGH 400 PANEL#MA2 LIBRARY (size:18.1KB)

CHANNEL CHART

TOUGH 400 PANEL#DMX-CN (size:329.4KB)

DRAWING

TOUGH 400 PANEL#CAD (size:572.4KB)

LIBRARY

TOUGH 400 PANEL#TIGER (size:2.9KB)
