Products
-
-
OPTICAL
19x20W RGBW
-
LUMEN OUTPUT
7,430 lm
-
ANGLE
10°-51°
-
MEASUREMENT
303*192*361mm
-
WEIGHT
10KG
Product
Parameters
Optical
Light Source: 19 pcs 20W RGBW 4 in 1 LED
Beam Angle: 10°-51°
Luminaire Output: 7,430lm
Illuminance (10°): 9,350 lux @ 5m
Illuminance (51°): 840 lux@ 5m
PWM Options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz
Dynamic effect
LED: section control
Selectable Pan Ranges: 180°, 360°, 540°
Selectable Tilt Ranges: 90°, 180°, 260°
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-20Hz, selectable multiple strobe effects with different speeds.
Zoom: Motorized
Color Mixing：RGBW mixing or CMY mixing
Appearance
Size: 303*192*361mm
Weight: 10KG
Housing Colors: Black
Housing Material: Aluminum alloy
IP rated: IP65
Connection
Control Protocol: DMX, RDM
DMX Channels: 56/54/33/22/17/15/54MS/33MS
3 pin XLR input/output
USB update enabled
Electrical / Temperature
Input Voltage: 100V-240V, 50/60Hz
Power and Current: 400W, 1.8A @ 230V, 50Hz
Working temperature: -40℃-45℃
Startup temperature: -20℃-45℃
 |
LED SOURCE | |||
RED | GREEN | BLUE | WHITE |
SECTION CONTROL 19x20W LED |
 |
PHOTOMETRICS |
 |
