Products
-
-
OPTICAL
19x20W RGBW
-
LUMEN OUTPUT
5,500 lm
-
ANGLE
9°-48°
-
MEASUREMENT
412*306*477mm
-
WEIGHT
26KG
Product
Parameters
Optical
Light Source: 19 pcs 20W RGBW 4 in 1 LED
Color Temperature: 2800K-10000K adjustable
Beam Angle: 9°-48°
Luminaire Output: 5,500lm
Illuminance (9°):9,500lux @ 5m
Illuminance (48°): 750lux @ 5m
PWM Options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz
Dynamic effect
LED: pixel control
Selectable Pan Ranges: 180°, 360°, 540°
Selectable Tilt Ranges: 90°, 180°, 270°
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-20Hz, selectable multiple strobe effects with different speeds.
Zoom: Motorized
Color Mixing：RGBW mixing or CMY mixing
Appearance
Size: 412*306*477mm
Weight: 26KG
Housing Colors: black or white
IP Rated: IP65
Connection
Control Protocol: DMX, RDM, ArtNet, Kling-Net, sACN, WDMX(*optional)
DMX (Single Mode): 20, 96, 178, 216
DMX (Dual Mode) Movement: 8, 20, 26
DMX (Dual Mode) Pixel: 57, 76, 152
Control Mode: DMX, Manual, Auto
IP65 rated 3 pin XLR input/output
IP65 rated power input
Electrical / Temperature
Input Voltage: 100V-240V, 50/60Hz
Power and Current: 440W, 2A @ 230V, 50Hz
Working temperature: -40℃-45℃
Startup temperature: -20℃-45℃
 |
LED SOURCE | |||
RED | GREEN | BLUE | WHITE |
PIXEL CONTROL 19x20W LED |
 |
PHOTOMETRICS |
 |
