OPTICAL

9x RGBL/RGBW
LUMEN OUTPUT

6,831 lm
ANGLE

15°, 25°, 35°
MEASUREMENT

524*200*285mm
WEIGHT

5.4KG

Product

Parameters

Optical

Light Source: 9 pcs RGBL/RGBW 4 in 1 LED

LER (Limunous Efficiency Ratio): 38lm/W

Color Temperature: 1800-10000K

Optics Angle: 6°/15°/25°/35°

Luminaire Output: 6,831lm

PWM Options: 600Hz, 1200Hz, 4000Hz, 6000Hz, 15000Hz

Dynamic effect

Dimmer: 0-100% electronics, 4 dimming curves options.

Strobe: 0-25Hz, selectable multiple strobe effects with different speeds.

Appearance

Size: 524*200*285mm

Weight: 5.4KG

Housing Colors: sky Grey

Housing Material: Magnesium alloy

IP rated: IP66

Connection

Control Protocol: DMX, RDM.

Input cable tail with 3-pin XLR connectors, power input cable tail

Electrical / Temperature

Input Voltage: 200V-240V, 50/60Hz

Power: 180W

Working temperature: -40℃-45℃

Startup temperature: -20℃-45℃

Technology

Support

Technical documents are updated irregularly

USER MANUAL

CL-1804 PANEL#MANUAL-CN (size:3.8MB)

LIBRARY

CL-1804 PANEL#GDTF_Build_No_1 (size:615.0KB)

USER MANUAL

CL-1804 PANEL#MANUAL-EN (size:4.7MB)

CHANNEL CHART

CL-1804 PANEL#DMX-EN (size:222.4KB)

LIBRARY

CL-1804 PANEL#MA2 LIBRARY (size:12.8KB)

CHANNEL CHART

CL-1804 PANEL#DMX-CN (size:426.2KB)

DRAWING

CL-1804 PANEL#CAD (size:232.4KB)

LIBRARY

CL-1804 PANEL#TIGER (size:2.5KB)
