Home

OPTICAL

1024x0.6W RGBW
LUMEN OUTPUT

24,857 lm
ANGLE

120°
MEASUREMENT

1000*108*179mm
WEIGHT

8.5KG

Product

Parameters

Optical

Light Source: 1024 pcs 0.6W RGBW 4 in 1 LED
Beam Angle: 120°
Luminaire Output: 24,857lm
Illuminance: 26,700lux @ 2m
PWM Options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz

Dynamic effect

Color System: RGBW mixing
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-25Hz, selectable multiple strobe effects with different speeds.

Appearance

Size: 1000*108*179mm
Weight: 8.5KG
Housing Colors: Black
Housing Material: Aluminum alloy
IP Rated: IP65

Connection

Control Protocol: DMX, RDM
DMX channels:15, 79, 149, 181
IP65 rated 3 pin XLR input/output

Electrical / Temperature

Input Voltage: AC 200V-240V 50Hz
Power: 610W
Temperature (Ambient): -5℃ to 45℃

Technology

Support

Technical documents are updated irregularly

USER MANUAL

TOUGH 500 S BAR#MANUAL-CN (size:1.0MB)

LIBRARY

TOUGH 500 S BAR#GDTF_Build_No_1 (size:966.8KB)

USER MANUAL

TOUGH 500 S BAR#MANUAL-EN (size:7.2MB)

CHANNEL CHART

TOUGH 500 S BAR#DMX-EN (size:398.0KB)

LIBRARY

TOUGH 500 S BAR#MA2 LIBRARY (size:32.1KB)

CHANNEL CHART

TOUGH 500 S BAR#DMX-CN (size:405.9KB)

DRAWING

TOUGH 500 S BAR#CAD (size:363.6KB)

LIBRARY

TOUGH 500 S BAR#TIGER (size:3.1KB)
