Products
-
-
OPTICAL
37x20W RGBW
-
LUMEN OUTPUT
11,000 lm
-
ANGLE
12°-52°
-
MEASUREMENT
393*298*444mm
-
WEIGHT
18KG
Product
Parameters
Optical
Light Source: 37 pcs 20W RGBW 4 in 1 LED
Beam Angle: 12°-52°
Luminaire Output: 11,000lm
Illuminance (12°): 15,000lux @ 5m
Illuminance (52°): 1400lux @ 5m
PWM options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz
Dynamic effect
LED: section control
Selectable Pan Ranges: 180°, 360°, 540°
Selectable Tilt Ranges: 90°, 180°, 270°
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-25Hz, selectable multiple strobe effects with different speeds.
Zoom: Motorized
Color Mixing：RGBW mixing or CMY mixing
Appearance
Size: 393*298*444mm
Weight: 18KG
Housing Colors: Black
Housing Material: High-impact flame-retardant polymer
Connection
Control Protocol: DMX, RDM
DMX Channels: 21, 62, 71, 107
3 pin XLR input/output
Electrical / Temperature
Input Voltage: 100V-240V, 50/60Hz
Power and Current: 890W, 3A @ 230V, 50Hz
Temperature (Ambient): -5℃ to 45℃
 |
LED SOURCE | |||
RED | GREEN | BLUE | WHITE |
SECTION CONTROL 37x20W LED |
 |
PHOTOMETRICS |
 |
