OPTICAL
500W LED
-
LUMEN OUTPUT
17,000 lm
-
ANGLE
6.5°-45°
-
MEASUREMENT
455*319*723mm
-
WEIGHT
40KG
Product
Parameters
Optical
Light Source: 500W white LED module
Color Temperature: 6,800K
Beam Angle: 6.5°-45°
Luminaire Output: 17,000lm
Illuminance (6.5°): 36,300lux @ 5m
Illuminance (45°): 2,100lux @ 5m
PWM Options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 15000Hz
Dynamic effect
Selectable Pan Ranges: 180°, 360°, 540°
Selectable Tilt Ranges: 90°, 180°, 270°
Colors: 7+white, split colors, rainbow effects at variable speeds.
Colors: CMY, CTO
Gobos 1: 7 glass rotating gobos+open, interchangeable gobos, indexing, rainbow effects at variable speeds
Gobos 2: 8 metal gobos+open, rainbow effects at variable speeds
Animation wheel: animation effect at variable speeds.
Dimmer: 0-100% electronics, 4 dimming curves options.
Strobe: 0-20Hz, selectable multiple strobe effects with different speeds.
Focus: Motorized
Zoom: Motorized
Frost 1: light frost effect
Frost 2: medium frost effect
Iris: Motorized
Prism: 5-facet prism, rotating at variable speeds.
Appearance
Size: 455*319*723mm
Weight: 40KG
Housing Colors: black or white
IP Rated: IP65
Connection
Control Protocol: DMX, RDM, ArtNet, sACN, WDMX(*optional)
DMX Channels: 26, 33
IP65 rated 3 pin XLR input/output
IP65 rated power input
Electrical / Temperature
Input Voltage: 100V-240V, 50/60Hz
Power and Current: 670W, 3A @ 230V, 50Hz
Working temperature: -40°-45°
Startup temperature: -20°-45°
 |
|
COLOR WHEEL | ||||||
 | ||||||
COLOR 1 | COLOR 2 | COLOR 3 | COLOR 4 | COLOR 5 | COLOR 6 | COLOR 7 |
ROTATING GOBO | ||||||
 | ||||||
R GOBO 1 | R GOBO 2 | R GOBO 3 | R GOBO 4 | R GOBO 5 | R GOBO 6 | R GOBO 7 |
STATIC GOBO | ||||||||
 | ||||||||
S GOBO 1 | S GOBO 2 | S GOBO 3 | S GOBO 4 | S GOBO 5 | S GOBO 6 | S GOBO 7 | S GOBO 8 | S GOBO 9 |
PRISM | FROST | ||
 |  |  | |
5-CIRCULAR PRISM |
| LIGHT | MEDIUM |
ANIMATION |
 |
PHOTOMETRICS |
 |
